NU311 Cylindrical Roller Bearing Steel Gcr15 Stainless Steel OPEN Roller Bearng Bore Size 10mm

Product Details:

Place of Origin:	Shandong,China
Brand Name:	HANSEL
Certification:	ISO9001:2000
Model Number:	NU311EM

Payment & Shipping Terms:

Minimum Order Quantity:	10 pieces
Price:	$7.89/pieces 10-99 pieces
Delivery Time:	If stock, in 7days or based on your order quantity

Get Best Price Contact Now

Detail Information
Product Description

Detail Information
Type:	Roller	Structure:	Taper
Applicable Industries:	Manufacturing Plant, Machinery Repair Shops	Precision Rating:	P0 P5 P6
Seals Type:	ZZ RS	Number Of Row:	Single Row
Product Name:	Spherical Roller Bearing	Application:	Automotive.tractor.construction Machinery.rolling Mill
Material:	Chrome Steel GCr15	Feature:	Stable Performance:low Voice
Service:	OEM Service.Design Service	Quality:	100% Inspection
Precision:	P0 P4 P6 P2	Lubrication:	Oil Grease

Product Description

Overview

Product description:

_{Cylindrical roller bearings have high load-bearing capacity, high-speed performance, wear resistance and ease of installation, and are suitable for various mechanical equipment.}

_{Cylindrical roller bearings are mainly used in the automotive industry, aerospace industry, railway transportation, heavy machinery, power industry, etc.}

_{We always adhere to customer-centricity and provide a full range of pre-sales, sales and after-sales services. No matter what problem you encounter, we will be happy to answer and solve it for you.}

Type	Single Row Cylindrical Roller Bearing
Model No.	NU311EM
Material	Bearing Steel,Chrome steel
Size	5512029mm

Specifications

Boundary dimensions(mm)									Limiting speeds(rpm)	Mass(Kg)
d	D	B	rs min	r1s min	Grease	Oil	(Approx.)	Bearing Number
50	80	16	1	0.6	8,900	11,000	0.295	NU1010
25	47	12	0.6	0.3	16,000	19,000	0.092	NU1005
30	55	13	1	0.6	14,000	16,000	0. 13	NU1006
35	62	14	1	0.6	12,000	15,000	0. 179	NU1007
20	47	14	1	0.6	15,000	18,000	0. 122	NU204E
25	52	15	1	0.6	13,000	15,000	0. 151	NU205E
30	62	16	1	0.6	11,000	13,000	0.226	NU206E
35	72	17	1.1	0.6	9,500	11,000	0.327	NU207E
40	80	18	1.1	1.1	9,400	11,000	0.378	NU208
40	80	18	1.1	1.1	8,500	10,000	0.426	NU208E
45	85	19	1.1	1.1	8,400	9,900	0.432	NU209
45	85	19	1.1	1.1	7,600	9,000	0.495	NU209E
50	90	20	1.1	1.1	7,600	9,000	0.47	NU210
50	90	20	1.1	1.1	6,900	8, 100	0.54	NU210E
55	100	21	1.5	1.1	6,900	8,200	0.638	NU211
55	100	21	1.5	1.1	6,300	7,400	0.718	NU211E
60	110	22	1.5	1.5	6,400	7,600	0.818	NU212
60	110	22	1.5	1.5	5,800	6,800	0.923	NU212E
65	120	23	1.5	1.5	5,900	7,000	1.02	NU213
65	120	23	1.5	1.5	5,400	6,300	1.21	NU213E
70	125	24	1.5	1.5	5,500	6,500	1. 12	NU214
70	125	24	1.5	1.5	5,000	5,900	1.3	NU214E
75	130	25	1.5	1.5	5, 100	6,000	1.23	NU215
75	130	25	1.5	1.5	4,700	5,500	1.41	NU215E
80	140	26	2	2	4,800	5,700	1.5	NU216
80	140	26	2	2	4,400	5, 100	1.67	NU216E
85	150	28	2	2	4,500	5,300	1.87	NU217
85	150	28	2	2	4, 100	4,800	2.11	NU217E
90	160	30	2	2	4,300	5,000	2.3	NU218
90	160	30	2	2	3,900	4,600	2.44	NU218E
95	170	32	2.1	2.1	4,000	4,700	2.78	NU219
95	170	32	2.1	2.1	3,600	4,300	3.02	NU219E
100	180	34	2.1	2.1	3,800	4,500	3.33	NU220
100	180	34	2.1	2.1	3,500	4, 100	3.66	NU220E
105	190	36	2.1	2.1	3,600	4,300	3.95	NU221
110	200	38	2.1	2.1	3,400	4,000	4.63	NU222
