Grease Lubricated SYJ75TF Y-Bearing Plummer Block Unit 75mm with Chrome Steel GCr15
Product Details:
| Place of Origin: | Shandong, China |
| Brand Name: | HANSEL |
| Model Number: | SYJ75TF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 8 pieces |
|---|---|
| Price: | $35.89/pieces 8-999 pieces |
| Delivery Time: | If stock, in 7days or based on your order quantity |
|
Detail Information |
|||
| Type: | Pillow Block | Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Retail, Construction Works , Energy & Mining, Other |
|---|---|---|---|
| Precision Rating: | P0P6P5P4P2 | Product Name: | Tapered Roller Beairngs |
| Material: | Chrome Steel GCr15 | Application: | Automotive.tractor.construction Machinery.rolling Mill |
| Feature: | Stable Performance:low Voice | Cage: | Steel Cage.copper Cage.nylon Cage |
| Lubrication: | Grease Lubricated | Certificate: | ISO9001:2008 |
| Vibration: | V1 V2 V3 V4 | Stock: | Great Supplying Ability |
| Clearance: | C2 C0 C3 C4 C5 | ||
Product Description
Product Description
Pillow block bearing combines an external spherical bearing with a bearing housing. Most of the outer spherical bearings are made of spherical outer diameter, and are installed together with the bearing housing with a spherical inner hole, and the structure is diverse, and the versatility and interchangeability are good.
Specification
TYPE | Shaft -∅ in mm | Dimensions in mm | Weight (kg) | ||||||||
Typ | g | w | Bi | n | ds | ||||||
UCP201 | 12 | 15 | 62 | 31 | 12,7 | M10 | 0,63 | ||||
UCP202 | 15 | 15 | 62 | 31 | 12,7 | M10 | 0,63 | ||||
UCP203 | 17 | 15 | 62 | 31 | 12,7 | M10 | 0,63 | ||||
UCP204 | 20 | 15 | 65 | 31 | 12,7 | M10 | 0,65 | ||||
UCP205 | 25 | 16 | 70 | 34 | 14,3 | M10 | 0,79 | ||||
UCP206 | 30 | 18 | 83 | 38,1 | 15,9 | M14 | 1,3 | ||||
UCP207 | 35 | 19 | 94 | 42,9 | 17,5 | M14 | 1,6 | ||||
UCP208 | 40 | 19 | 100 | 49,2 | 19 | M14 | 2 | ||||
UCP209 | 45 | 20 | 108 | 49,2 | 19 | M14 | 2,2 | ||||
UCP210 | 50 | 22 | 114 | 51,6 | 19 | M16 | 2,8 | ||||
UCP211 | 55 | 22 | 126 | 55,6 | 22,2 | M16 | 3,4 | ||||
UCP212 | 60 | 25 | 138 | 65,1 | 25,4 | M16 | 4,8 | ||||
UCP213 | 65 | 27 | 150 | 65,1 | 25,4 | M20 | 5,7 | ||||
UCP214 | 70 | 27 | 156 | 74,6 | 30,2 | M20 | 7 | ||||
UCP215 | 75 | 28 | 163 | 77,8 | 33,3 | M20 | 7,6 | ||||
UCP216 | 80 | 30 | 175 | 82,6 | 33,3 | M20 | 9 | ||||
UCP217 | 85 | 32 | 187 | 85,7 | 34,1 | M20 | 11,5 | ||||
UCP218 | 90 | 34 | 200 | 96 | 39,7 | M22 | 14,3 | ||||
Related Products
Company Profile
Wide Product Range to Choose From
Ah-factory Co., Ltd. is located in Yandian, Linqing, which is the biggest bearing market in China. Ah-factory bearing's main products are deep groove ball bearings, spherical roller bearings, tapered roller bearings, cylindrical roller bearings, spherical plain bearings, pillow block bearings, needle roller bearings, and all kinds of bearing parts and seals.
