23126 23128 23130 23132 23134 23134K 23134KW33C3 23134W33C3 Spherical Roller Bearing
Product Details:
| Place of Origin: | Shandong, China |
| Brand Name: | MOTIONTECH and HANSEL |
| Model Number: | 23126K |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 pieces |
|---|---|
| Price: | $15.68/pieces 10-999 pieces |
| Packaging Details: | 1.Kraft paper+Cartons+Wooden case pallets<br>2.Plastice tube+Cartons+Wooden case pallets;<br>3.Single box+Outer carton+Wooden case pallets;<br>4.According to your requirements. |
| Delivery Time: | If stock, in 7days or based on your order quantity |
| Supply Ability: | 10000 Piece/Pieces per Month |
|
Detail Information |
|||
| Type: | Roller | Structure: | Spherical |
|---|---|---|---|
| Applicable Industries: | Manufacturing Plant, Machinery Repair Shops, Construction Works , Energy & Mining, Other | Precision Rating: | High Precision |
| Seals Type: | Oil Coated | Number Of Row: | Double Row |
| Product Name: | Spherical Roller Bearing 22210CC/W33/C3 | Material: | Chrome Steel GCR15 |
| Feature: | Long Life High Speed | Service: | OEM Service.Design Service |
Product Description
Product Description
Specification
Boundary dimensions(mm) | Limiting speeds(rpm) | Mass(Kg) | Bearing Number | ||||||||
d | D | B | rs min | Grease | Oil | (Approx.) | |||||
130 | 210 | 64 | 2 | 1,300 | 2,000 | 8.2 | 23126K | ||||
130 | 210 | 64 | 2 | 1,300 | 2,000 | 8.2 | 23126KW33C3 | ||||
130 | 210 | 64 | 2 | 1,300 | 2,000 | 8.47 | 23126W33C3 | ||||
140 | 225 | 68 | 2.1 | 1,200 | 1,800 | 10.2 | 23128 | ||||
140 | 225 | 68 | 2.1 | 1,200 | 1,800 | 9.86 | 23128K | ||||
140 | 225 | 68 | 2.1 | 1,200 | 1,800 | 9.86 | 23128KW33C3 | ||||
140 | 225 | 68 | 2.1 | 1,200 | 1,800 | 10.2 | 23128W33C3 | ||||
150 | 250 | 80 | 2.1 | 1, 100 | 1,700 | 15.6 | 23130 | ||||
150 | 250 | 80 | 2.1 | 1, 100 | 1,700 | 15. 1 | 23130K | ||||
150 | 250 | 80 | 2.1 | 1, 100 | 1,700 | 15. 1 | 23130KW33C3 | ||||
150 | 250 | 80 | 2.1 | 1, 100 | 1,700 | 15.6 | 23130W33C3 | ||||
160 | 270 | 86 | 2.1 | 1,000 | 1,600 | 19.8 | 23132 | ||||
160 | 270 | 86 | 2.1 | 1,000 | 1,600 | 19.2 | 23132K | ||||
160 | 270 | 86 | 2.1 | 1,000 | 1,600 | 19.2 | 23132KW33C3 | ||||
160 | 270 | 86 | 2.1 | 1,000 | 1,600 | 19.8 | 23132W33C3 | ||||
170 | 280 | 88 | 2.1 | 960 | 1,500 | 21.5 | 23134 | ||||
170 | 280 | 88 | 2.1 | 960 | 1,500 | 20.8 | 23134K | ||||
170 | 280 | 88 | 2.1 | 960 | 1,500 | 20.8 | 23134KW33C3 | ||||
170 | 280 | 88 | 2.1 | 960 | 1,500 | 21.5 | 23134W33C3 | ||||
Spherical roller bearings are principally provided with two rows of symmetrical spherical rollers and a common sphere raceway in out ring, the two inner ring raceways are included at an angle to the bearing axial. The bearings have good self-aligning ability and can operate when the shaft deflection under load or the shaft deflection under load or the shaft misaligningment in mounting,and their permissible aligning angle is 1 to 2.5 degree. This type of bearings has heavy load carrying capacity and anti-impact ability, in addition to radial loads, they also can carry axial loads in two directions. In general, this type of bearings permit a low limiting speed.
Related Products
Company Profile
Shandong Ah-factory Import & Export Co.,Ltd
Shandong Ah-factory mport & Export Co.,Ltd is located in Jinan,Shandong province. Our predecessor is committed to the export of bearings, sleeves and seals, which has more than 16 years’ experience. We have cooperated with more than 1000 bearing factories and own shares in a number of factories.
Exhibition
Packing & Delivery
Why Choose Us
1. Face to face with the factory directly
2. Many years industry deep cultivation
3. Support sample customization and OEM service
4. Production quality assurance
5. Raw material quality assurance
6. After-sales guarantee
2. Many years industry deep cultivation
3. Support sample customization and OEM service
4. Production quality assurance
5. Raw material quality assurance
6. After-sales guarantee
FAQ
Q1:Is you company factory or Trade Company?
We have our own factory, our type is factory +trade.
Q2: Could you accept OEM and customize?
Yes, we can customize it for you according to the sample or drawing.
Q3: What is the MOQ of your company?
Our MOQ is normally 10pcs, anyway lower MOQ is also acceptable with a little higher cost, as the more you purchase the cheaper cost you could get.
Q4: Could you tell me the material of your bearing?
We have chrome steel, stainless steel, and ceramic.
Q5: Could you offer door-to-door service?
Yes, by express(DHL, FedEx, TNT, EMS,4-10 days to your city.)
Q6: Could you tell me the delivery time of your doors?
If stock, in 7-14days or based on your order quantity.
